1、仿威圖配電柜保溫柜其柜型結構，仍是在仿威圖野外機柜的基礎上演變而來，全體野外防水作用很好，密封性；

1. The insulation cabinet of the imitation Weitu distribution cabinet is first of all based on its cabinet structure, which is still evolved from the imitation Weitu outdoor cabinet. The overall outdoor waterproofing effect is very good, and the sealing is excellent;

2、保溫柜在野外運用的時候，一般多是在北方嚴寒的當?shù)兀鞙囟饶艿竭_零下20多度，甚更低！那么為了確保柜內元器件正常運轉作業，必須要保持柜內一定的溫度，方法有幾種。一種是貼復鋁箔保溫棉，厚度一般在10-20mm以上，甚更厚。這種保溫棉的保溫作用很好，也可以再配一個加熱器和一個溫控器，泰予出產的仿威圖加熱器和溫控器可以搭配運用，溫控器設定好溫度今后，當環境溫度到達設定溫度值時，加熱器就開始作業，這樣柜內部溫度也會慢慢升高。

2. When insulated cabinets are used in the wild, they are usually located in cold northern regions, with temperatures reaching minus 20 degrees Celsius or even lower in winter! So in order to ensure the normal operation of the components inside the cabinet, it is necessary to maintain a certain temperature inside the cabinet. There are several methods. One method is to apply aluminum foil insulation cotton, with a thickness generally of 10-20mm or even thicker. This type of insulation cotton has a good insulation effect, and can also be paired with a heater and a temperature controller. The imitation Weitu heater and temperature controller produced by Taiyu can be used together. After the temperature controller is set, when the ambient temperature reaches the set temperature value, the heater will start working, and the temperature inside the cabinet will gradually increase.

3、有些保溫柜在野外運用時，并不是裝元器件，而是再里面裝水管和壓力表，閥門等。這種也是操控水站，或許其它什么水處理體系設備的，冬天溫度低，不能讓水管結冰凍住，這時候也需求給柜體進行保溫或許加熱。

3. Some insulation cabinets are not equipped with components when used in the wild, but with water pipes, pressure gauges, valves, etc. inside. This is also the operation of water stations, and perhaps other water treatment system equipment. In winter, the temperature is low and the water pipes cannot freeze. At this time, it is also necessary to insulate or heat the cabinet.

4、在制造仿威圖機柜（保溫柜）的時候，需求注意，柜內要盡可能的平整，除了非必要的接地螺柱以外，其它螺絲螺柱要盡可能的防止，因為內部越是平坦，后期貼保溫棉就越方便，保溫作用也越好。甚不需求運用野外機柜空調或許冷熱交換器。

4. When manufacturing imitation Weitu cabinets (insulation cabinets), it is important to note that the interior of the cabinet should be as flat as possible. Except for unnecessary grounding screws, other screws and screws should be prevented as much as possible. The flatter the interior, the more convenient it is to apply insulation cotton later on, and the better the insulation effect. Not even requiring the use of outdoor cabinet air conditioning or heat exchangers.

5、仿威圖野外接線箱也可以做保溫結構，原理都是相同的，只不過反面的掛墻附件，要直接焊接上去，不能運用通用規范的AE箱壁掛件

5. Imitation of Weitu outdoor junction boxes can also be used for insulation structures, and the principle is the same. However, the wall mounted accessories on the opposite side need to be directly welded on, and the AE box wall mounted accessories in general specifications cannot be used

6、其他的柜型，例如仿威圖琴式操作臺、PC電腦柜、工業電腦操控柜、鋁合金懸臂體系、防水端子盒、PS九折型材柜、威圖電柜等要想做保溫結構，也可以考慮，但是在制造工藝上會比較復雜，這個要看詳細的現場環境要求。

6. Other cabinet types, such as imitation Weituqin style operation console, PC computer cabinet, industrial computer control cabinet, aluminum alloy cantilever system, waterproof terminal box, PS 90 fold profile cabinet, Weituo electrical cabinet, etc., can also be considered for insulation structure. However, the manufacturing process may be more complex, which depends on the detailed on-site environmental requirements.
